B747
B747
PPG is the sole manufacturer of original-equipment and replacement windshields and side cockpit windows for Boeing 747-100/200/300/400 aircraft. Featuring glass-faced acrylic and all-glass designs, chemically strengthened glass, advanced heating and moisture seals, these transparencies offer outstanding durability, weight savings and proven reliability.
- Center structural glass ply protects against damage; tempered glass ply prevents glass particle ingress during bird strikes.
- Triple fail-safe design passes pressure tests even with broken glass plies, allowing cold dispatch.
- Urethane interlayer enhances adhesion, resists delamination, extends service life, and reduces cold chipping.
- NESTARON® anti-ice system delivers uniform heating and clear optics.
- Side cockpit windows available in all-glass or lightweight glass-faced acrylic designs, saving up to 37 lbs.
- Side windows feature chemical and abrasion-resistant glass plies and fail-safe structural layers.
- Antifog systems provide superior heat uniformity and optical clarity.
- Full interchangeability across 747 models reduces inventory and installation costs.
Discover the Future of Flight
Have questions or need support for your aerospace project? Contact PPG’s aerospace team today for guidance and tailored solutions.
Accordion collapsed
| Window Type | PPG Part Number | OEM Part Number |
|---|---|---|
| WINDSHIELD #1 L/H | BAC012909 | 60B10028-11/NP-103801-113 |
| WINDSHIELD #1 L/H | BAC012911 | 60B10028-23/NP-103801-117 |
| WINDSHIELD #1 R/H | BAC013009 | 60B10028-12/NP-103801-114 |
| WINDSHIELD #1 R/H | BAC013011 | 60B10028-24/NP-103801-118 |
| WINDSHIELD #2 L/H | BAC021504 | 141U4822-11 |
| WINDSHIELD #2 R/H | BAC021604 | 141U4822-12 |
| WINDSHIELD #3 L/H | BAC021704 | 141U4832-11 |
| WINDSHIELD #3 R/H | BAC021804 | 141U4832-12 |
| NP-103801-121 | BAC012913 | NP-103801-121 |
| NP-103801-122 | BAC013013 | 60B10028-28/NP-103801-122 |
| 747 #3 side panel | 141600-03 | 65B07640-19 |
| 747 #3 side panel | 141600-04 | 65B07640-20 |
| Hump Seal Repair Kit | HSKBOEINGWB |
Window Type
WINDSHIELD #1 L/H
PPG Part Number
BAC012909
OEM Part Number
60B10028-11/NP-103801-113
Window Type
WINDSHIELD #1 L/H
PPG Part Number
BAC012911
OEM Part Number
60B10028-23/NP-103801-117
Window Type
WINDSHIELD #1 R/H
PPG Part Number
BAC013009
OEM Part Number
60B10028-12/NP-103801-114
Window Type
WINDSHIELD #1 R/H
PPG Part Number
BAC013011
OEM Part Number
60B10028-24/NP-103801-118
Window Type
WINDSHIELD #2 L/H
PPG Part Number
BAC021504
OEM Part Number
141U4822-11
Window Type
WINDSHIELD #2 R/H
PPG Part Number
BAC021604
OEM Part Number
141U4822-12
Window Type
WINDSHIELD #3 L/H
PPG Part Number
BAC021704
OEM Part Number
141U4832-11
Window Type
WINDSHIELD #3 R/H
PPG Part Number
BAC021804
OEM Part Number
141U4832-12
Window Type
NP-103801-121
PPG Part Number
BAC012913
OEM Part Number
NP-103801-121
Window Type
NP-103801-122
PPG Part Number
BAC013013
OEM Part Number
60B10028-28/NP-103801-122
Window Type
747 #3 side panel
PPG Part Number
141600-03
OEM Part Number
65B07640-19
Window Type
747 #3 side panel
PPG Part Number
141600-04
OEM Part Number
65B07640-20
Window Type
Hump Seal Repair Kit
PPG Part Number
HSKBOEINGWB
OEM Part Number
